| Home > Product > Hi-Frequency Spindle |
|
|
| MODEL |
|
KF-3 |
KF-3-T |
KF-3-1 |
KF-3-2 |
KF-3-2-T |
KF-3-3 |
KF-3-3-T |
Steel brg +
greased |
min-1 |
18,000 |
18,000 |
18,000 |
18,000 |
18,000 |
16,000 |
16,000 |
Ceramic brg +
greased |
min-1 |
24,000 |
24,000 |
24,000 |
24,000 |
24,000 |
24,000 |
24,000 |
Ceramic brg +
Oil-Air Lubrication |
min-1 |
33,000 |
|
30,000 |
30,000 |
|
30,000 |
30,000 |
| Power |
Kw |
5.5(7) |
5.5(7) |
11.2 |
11.2 |
11.2 |
15.2 |
15.2 |
| Voltage |
V |
220, 380 |
220, 380 |
380 |
380 |
380 |
380 |
380 |
| Pole |
P |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
| Tooling System |
|
BT30, HSK40E |
BT30, HSK40E |
BT30, HSK40E |
BT30, HSK40E |
BT30, HSK40E |
BT30, HSK40E |
BT30, HSK40E |
| Weight |
Kg |
20 |
20 |
30 |
30 |
30 |
45 |
45 |
Tool change
pressure |
Kg/㎠ |
5 |
5 |
30 |
30 |
30 |
35 |
35 |
| Torque |
Nm |
|
|
|
|
|
|
|
| Tool release |
|
Air |
HY(Booster) |
Air |
HY(Booster) |
HY(Booster) |
HY(Booster) |
HY(Booster) |
| Encoder |
Pulse |
|
|
|
|
|
|
|
Internal Coolant
Supply |
|
|
TSC Type |
|
|
TSC Type |
|
TSC Type |
| Application |
|
Engraving
Mook-up
Back light |
Engraving
Mook-up
Back light |
Mook-up
금형가공
고속가공 |
Mook-up
금형가공
고속가공 |
Mook-up
금형가공
고속가공 |
Mook-up
금형가공
고속가공 |
Mook-up
금형가공
고속가공 |
|
