MODEL   KFG-7.5 KFG-3.5 KFG-1.5
Steel brg + greased min-1 3450 / 1750 3450 / 1750 3450 / 1750
Ceramic brg + greased min-1
Ceramic brg + Oil-Air Lubrication min-1
Power Kw 7.5 3.75 1.5
Voltage V 220 / 380 220 / 380 220 / 380
Pole P 2 / 4 2 / 4 2 / 4
Tooling System
Weight Kg
Tool change pressure Kg/§² L : 50 L : 50 L : 50
Torque Nm 100 100 100
Tool release   150 150 150
Encoder Pulse 200 200 200
Internal Coolant Supply
Application   Grinding M/C Grinding M/C Grinding M/C
